BOMAG BW 174 AP AM

Bomag BW 174 AP AM
TECHNICAL CHARACTERISTICS B
Year 2007
MTC. 5900
The width of the compacted strip is 1680 mm
Working weight, t 9.2
The radius of rotation of the roller along the outer contour of the track, mm 2946
Speed of movement, km / h 10,4
Volume of a fuel tank, l 180
ENGINE
Manufacturer Kubota
Engine type V 3800 DI-T
Power, kW 74
Rotation speed, rpm 2600
Number of cylinders 4
Water cooling
Diesel fuel
The service brake is hydrostatic
Mechanical handbrake
VIBRATION DEVICE
The drive system is hydrostatic
Frequency, Hz 45/60
Amplitude of oscillations, mm 0,46 / 0,20
Centrifugal force, kN 88/75
