BOBCAT S630 HIGH FLOW

Bobcat S630 HIGH FLOW
Specifications
Nominal load capacity, kg 1040
Lifting height, mm 3073
Working weight, kg 3496
Rise of a frame Radial
Shifting load, kg 2079
Pump capacity (standard feed / high flow), l / min 87.1 / 115.5
System pressure in quick couplers, MPa 23.8-24.5
Speed ​​of movement, km / h 11,4
Speed ​​of movement (high - option), km / h 19,8
Length with standard bucket, mm 3474
Width with a standard bucket, mm 1880
Height with operator's cab, mm 2065
Wheelbase, 1150 mm
Kubota engine brand
V3307-DI-TE3 engine model
Fuel type / Cooling diesel. / Ri.
Maximum power at rpm, kW / hp rpm 54.6 (73.42) 2400
Torque at rpm, Nm rpm 264 1600
Number of cylinders / Working volume of cylinders 4 / 3,3
Fuel tank capacity 103.3
Weight during transportation, kg 3244
Standard tires (pneumatic) 12 x 16.5 PR12
Bobcat standard (pedal control / levers) Standard
